Online Guidance and Overseas Service Available
US $2900.00
US $3500.00 (Without shipping)(--17%)
Savings: US $-600.00
Support offline trading, please contact us for more information.
Add to cart
SPECS
| Application | Industrial Laser Engraving Cutting |
| Model number | R6090 |
| Engraving area | 600mm x900mm |
| Laser power | 80W/100W/130W |
| Laser tube type | Co2 Glass sealed laser tube |
| PC Interface | USB 2.0 and USB disk |
| Control system | DSP, Ruida controller |
| Operating system | Rdworks |
| Graphic format supported | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, etc |
| Drive type | Stepper motor |
| Cooling mode | Water Cooling |
| Working Table Surface | Blade/Honeycomb Working Table, Motorised Up-Down table |
| Working voltage | 110~240V/50~60Hz |
| Max speed | 1500 mm/s |
| Software resolution | 1000 DPI |
| Location precision | less than 0.01 mm |
| Red Dot positioning system | beam-combination mirror, different from ordinary red point |
| Package | Standard wooden case |
| Laser Class | Class 4 |
APPLICATION
FEATURES
- Equipped with high-speed RD DSP control system, work offline, with multi-color cutting function
- 2 color warning light, more safety
- Adopt industrial laser head, laser beam is stable and fast.
- Inline Beam Combiner accurately illuminates red dot over your material for improved accuracy and alignment
- Magnetic OVERRIDE SAFETY SWITCH, more reliable.
- 0-150mm electronic lift table, meet the needs of different thickness materials for carving.
- 2 way pass through, allow feeding bigger size material.
- Ethernet, USB2.0 and U-disk transmission, compatible with Windows/ios
- Full support for CorelDraw, AutoCAD, lightburn etc.
- CE and FDA certificate, more reliable.
